BSD10000XE/BSD11000XE/BSD11105XE/BSD11115XE
AEROBS
| Model | BSD10000XE | BSD11000XE | BSD11105XE | BSD11115XE |
| Engine Model | BS195FE | BS1100FE | BS1105FE | BS1115FE |
| Bore × Stroke (mm) | 95×75 | 110×85 | 105×85 | 115×92 |
| Displacement (cc) | 532 | 668 | 736 | 956 |
| Rated Frequency (Hz) | 50 | 50 | 50 | 50 |
| Rated Voltage (V) | 230 | 230 | 230 | 230 |
| Rated Power (kw) | 7.0 | 8.0 | 10 | 11 |
| Max.Power (kw) | 7.5 | 8.8 | 10.5 | 12 |
| Compression Ratio | 19.5:1 | 19.5:1 | 19.5:1 | 19.5:1 |
| Starting System | Electric Start | Electric Start | Electric Start | Electric Start |
| Fuel Tank Capacity (L) | 15 | 15 | 15 | 15 |
| N.W/G.W (kg) | 100/115 | 155/165 | 175/185 | 175/185 |
| Dimensions (L×W×H) (mm) | 720×492×655 | 790×598×715 | 790×598×715 | 790×598×715 |
| Quantity(20GP/40HQ) | 122/226 | 81/144 | 81/144 | 81/144 |
