| Model | BSWP20DI | BSWP30DI | BSWP40DI |
| Inlet/Outlet Dia (in/mm) | 2/50 | 3/80 | 4/100 |
| Lift (m) | 90 | 90 | 40 |
| Suction (m) | 6 | 6 | 6 |
| Volume (m³/h) | 32 | 44 | 93 |
| Engine Model | BS186FA(E) | BS192F(E) | BS192F(E) |
| Broke *Stroke (mm) | 86×72 | 92×75 | 92×75 |
| Displacement (cc) | 418 | 499 | 499 |
| Rated Rotation Speed (rpm) | 3600 | 3600 | 3600 |
| Rated Power (kw) | 6.3 | 8.6 | 8.6 |
| Lube Oil Capacity (L) | 1.65 | 1.65 | 1.65 |
| Fuel Tank Capacity (L) | 5.5 | 5.5 | 5.5 |
| Dimensions (L*W*H) (mm) | 580×480×630 | 570×480×620 | 570×480×620 |
| N.W/G.W (kg) | 63/65 | 76/78 | 78/80 |
| Quantity(20GP/40HQ) | 96/288 | 144/384 | 144/384 |
