BSWP20X
AEROBS
Equipped with the high - specification 170F/P - 2 power unit, it ensures abundant power output.
The surface treatment process of the water pump adopts shot blasting and baking finish, which enhances its corrosion resistance.
The internal components of the pump are precisely fitted, maintaining the optimal water discharge efficiency and overall performance.
It is paired with our company's Model V twin - cylinder frame, which minimizes the vibration of the whole unit and improves its stability and reliability.
| Model | BSWP20X |
| Engine Model | BS220X |
| Starting System | Recoil Start |
| Bore * Stroke (mm) | 70×55 |
| Displacement (cc) | 212 |
| Pump Type | Self-priming Pump |
| Dia.of Discharge (mm) | 50 |
| Dia.of Suction (mm) | 50 |
| Volume (m³/h) | 20 |
| Suction (m) | 6 |
| Lift (m) | 20 |
| Dimensions (L*W*H) (mm) | 540×430×445 |
| N.W/G.W (kg) | 24/26 |
| Quantity(20GP/40HQ) | 280/690 |
